HL-A2FM HYDRAULIC MOTORS
Fixed Displacement Axial Piston Motor for Closed Circuit

Fixed Displacement Axial Piston Motor for Closed Circuit

The HL-A2FM fixed displacement motor is built for hydraulic drive systems, delivering high torque, outstanding efficiency, and fast dynamic response. Designed for heavy-duty machinery, this motor ensures reliable power and stability in demanding applications.

  • Displacement 10-200 cm³/rev
  • Nominal pressure 400 bar
  • Max. allowable pressure 450 bar
Request a Quote
Technical Data
Size
Displacement
(cm³/rev)
Max. speed (rpm)
nnom
Nmax
Max. Flow
(L/min)
Torque (Nm)
Δp=350 bar
Δp=400 bar
Details
10
10.3
8000
8800
57
66
Geometric displacement Vg cm³/rev 10.3
Max. rotation speed nnom rpm 8000
nmax rpm 8800
Inlet flow at nnom and Vg qv L/min 82
Torque at Vg Δp=350 bar T Nm 57
Δp=400 bar T Nm 66
Rotary stiffness c kNm/rad 0.92
Moment of inertia for rotary group JGR kgm² 0.0004
Max. angular acceleration α rad/s² 5000
Case volume V L 0.17
Weight (approx.) m kg 5.4
12
12
8000
8000
67
76
Geometric displacement Vg cm³/rev 12
Max. rotation speed nnom rpm 8000
nmax rpm 8000
Inlet flow at nnom and Vg qv L/min 96
Torque at Vg Δp=350 bar T Nm 67
Δp=400 bar T Nm 76
Rotary stiffness c kNm/rad 1.25
Moment of inertia for rotary group JGR kgm² 0.0004
Max. angular acceleration α rad/s² 5000
Case volume V L 0.17
Weight (approx.) m kg 5.4
16
16
8000
8000
89
102
Geometric displacement Vg cm³/rev 16
Max. rotation speed nnom rpm 8000
nmax rpm 8000
Inlet flow at nnom and Vg qv L/min 128
Torque at Vg Δp=350 bar T Nm 89
Δp=400 bar T Nm 102
Rotary stiffness c kNm/rad 1.59
Moment of inertia for rotary group JGR kgm² 0.0004
Max. angular acceleration α rad/s² 5000
Case volume V L 0.17
Weight (approx.) m kg 5.4
23
22.9
6300
6900
128
146
Geometric displacement Vg cm³/rev 22.9
Max. rotation speed nnom rpm 6300
nmax rpm 6900
Inlet flow at nnom and Vg qv L/min 144
Torque at Vg Δp=350 bar T Nm 128
Δp=400 bar T Nm 146
Rotary stiffness c kNm/rad 2.56
Moment of inertia for rotary group JGR kgm² 0.0012
Max. angular acceleration α rad/s² 6500
Case volume V L 0.2
Weight (approx.) m kg 9.5
28
28.1
6300
6900
157
179
Geometric displacement Vg cm³/rev 28.1
Max. rotation speed nnom rpm 6300
nmax rpm 6900
Inlet flow at nnom and Vg qv L/min 177
Torque at Vg Δp=350 bar T Nm 157
Δp=400 bar T Nm 179
Rotary stiffness c kNm/rad 2.93
Moment of inertia for rotary group JGR kgm² 0.0012
Max. angular acceleration α rad/s² 6500
Case volume V L 0.2
Weight (approx.) m kg 9.5
32
32
6300
6900
178
204
Geometric displacement Vg cm³/rev 32
Max. rotation speed nnom rpm 6300
nmax rpm 6900
Inlet flow at nnom and Vg qv L/min 202
Torque at Vg Δp=350 bar T Nm 178
Δp=400 bar T Nm 204
Rotary stiffness c kNm/rad 3.12
Moment of inertia for rotary group JGR kgm² 0.0012
Max. angular acceleration α rad/s² 6500
Case volume V L 0.2
Weight (approx.) m kg 9.5
45
45.6
5600
6200
254
290
Geometric displacement Vg cm³/rev 45.6
Max. rotation speed nnom rpm 5600
nmax rpm 6200
Inlet flow at nnom and Vg qv L/min 255
Torque at Vg Δp=350 bar T Nm 254
Δp=400 bar T Nm 290
Rotary stiffness c kNm/rad 4.18
Moment of inertia for rotary group JGR kgm² 0.0024
Max. angular acceleration α rad/s² 14600
Case volume V L 0.33
Weight (approx.) m kg 13.5
56
56.1
5000
5500
351
401
Geometric displacement Vg cm³/rev 56.1
Max. rotation speed nnom rpm 5000
nmax rpm 5500
Inlet flow at nnom and Vg qv L/min 281
Torque at Vg Δp=350 bar T Nm 351
Δp=400 bar T Nm 401
Rotary stiffness c kNm/rad 5.94
Moment of inertia for rotary group JGR kgm² 0.0042
Max. angular acceleration α rad/s² 7500
Case volume V L 0.45
Weight (approx.) m kg 18
63
63
5000
5500
448
512
Geometric displacement Vg cm³/rev 63
Max. rotation speed nnom rpm 5000
nmax rpm 5500
Inlet flow at nnom and Vg qv L/min 315
Torque at Vg Δp=350 bar T Nm 448
Δp=400 bar T Nm 512
Rotary stiffness c kNm/rad 6.25
Moment of inertia for rotary group JGR kgm² 0.0042
Max. angular acceleration α rad/s² 7500
Case volume V L 0.45
Weight (approx.) m kg 18
80
80.4
4500
5000
501
573
Geometric displacement Vg cm³/rev 80.4
Max. rotation speed nnom rpm 4500
nmax rpm 5000
Inlet flow at nnom and Vg qv L/min 362
Torque at Vg Δp=350 bar T Nm 501
Δp=400 bar T Nm 573
Rotary stiffness c kNm/rad 8.73
Moment of inertia for rotary group JGR kgm² 0.0072
Max. angular acceleration α rad/s² 6000
Case volume V L 0.55
Weight (approx.) m kg 23
90
90
4500
5000
594
679
Geometric displacement Vg cm³/rev 90
Max. rotation speed nnom rpm 4500
nmax rpm 5000
Inlet flow at nnom and Vg qv L/min 405
Torque at Vg Δp=350 bar T Nm 594
Δp=400 bar T Nm 679
Rotary stiffness c kNm/rad 9.14
Moment of inertia for rotary group JGR kgm² 0.0072
Max. angular acceleration α rad/s² 6000
Case volume V L 0.55
Weight (approx.) m kg 23
107
106.7
4000
4400
696
796
Geometric displacement Vg cm³/rev 106.7
Max. rotation speed nnom rpm 4000
nmax rpm 4400
Inlet flow at nnom and Vg qv L/min 427
Torque at Vg Δp=350 bar T Nm 696
Δp=400 bar T Nm 796
Rotary stiffness c kNm/rad 11.2
Moment of inertia for rotary group JGR kgm² 0.0116
Max. angular acceleration α rad/s² 4500
Case volume V L 0.8
Weight (approx.) m kg 32
125
125
4000
4400
893
1021
Geometric displacement Vg cm³/rev 125
Max. rotation speed nnom rpm 4000
nmax rpm 4400
Inlet flow at nnom and Vg qv L/min 500
Torque at Vg Δp=350 bar T Nm 893
Δp=400 bar T Nm 1021
Rotary stiffness c kNm/rad 11.9
Moment of inertia for rotary group JGR kgm² 0.0116
Max. angular acceleration α rad/s² 4500
Case volume V L 0.8
Weight (approx.) m kg 32
160
160.4
3600
4000
1003
1146
Geometric displacement Vg cm³/rev 160.4
Max. rotation speed nnom rpm 3600
nmax rpm 4000
Inlet flow at nnom and Vg qv L/min 577
Torque at Vg Δp=350 bar T Nm 1003
Δp=400 bar T Nm 1146
Rotary stiffness c kNm/rad 17.4
Moment of inertia for rotary group JGR kgm² 0.022
Max. angular acceleration α rad/s² 3500
Case volume V L 1.1
Weight (approx.) m kg 45
180
180
3600
4000
1114
1273
Geometric displacement Vg cm³/rev 180
Max. rotation speed nnom rpm 3600
nmax rpm 4000
Inlet flow at nnom and Vg qv L/min 648
Torque at Vg Δp=350 bar T Nm 1114
Δp=400 bar T Nm 1273
Rotary stiffness c kNm/rad 18.2
Moment of inertia for rotary group JGR kgm² 0.022
Max. angular acceleration α rad/s² 3500
Case volume V L 1.1
Weight (approx.) m kg 45
200
200
2750
3000
313
357
Geometric displacement Vg cm³/rev 200
Max. rotation speed nnom rpm 2750
nmax rpm 3000
Inlet flow at nnom and Vg qv L/min 550
Torque at Vg Δp=350 bar T Nm 313
Δp=400 bar T Nm 357
Rotary stiffness c kNm/rad 57.3
Moment of inertia for rotary group JGR kgm² 0.0353
Max. angular acceleration α rad/s² 11000
Case volume V L 2.7
Weight (approx.) m kg 66
Size Displacement (cm³/rev) Max. speed (rpm) Max. Flow (L/min) Torque(Nm)
nnom nmax Δp=350 bar Δp=400 bar
10 10.3 8000 8800 57 66
12 12 8000 8000 67 76
16 16 8000 8000 89 102
23 22.9 6300 6900 128 146
28 28.1 6300 6900 157 179
32 32 6300 6900 178 204
45 45.6 5600 6200 254 290
56 56.1 5000 5500 351 401
63 63 5000 5500 448 512
80 80.4 4500 5000 501 573
90 90 4500 5000 594 679
107 106.7 4000 4400 696 796
125 125 4000 4400 893 1021
160 160.4 3600 4000 1003 1146
180 180 3600 4000 1114 1273
200 200 2750 3000 313 357
Features
  • proportional speed control Output speed is directly proportional to input flow and inversely proportional to displacement, ensuring precise operation.
  • torque adaptability Drive torque increases as the pressure difference between the motor’s high-pressure and low-pressure sides grows, providing powerful performance.
  • compact and efficient design Features a high power-to-weight ratio and optimized volumetric efficiency, making it ideal for space-constrained systems.
  • integrated axial piston design Built with a one-piece tapered piston with a piston ring, enhancing durability and efficiency.
Applications
Construction Machinery
Construction Machinery
Mining and Quarrying Equipment
Mining and Quarrying Equipment
Agricultural Machinery
Agricultural Machinery
